800W LED with CMY Moving Head Beam Spot Wash Framing Light

800W LED with CMY Moving Head Beam Spot Wash Framing Light

LED800BSWPro-2

LED800BSWPro-3

LED800BSWPro-4
800W LED with CMY Moving Head Beam Spot Wash Framing Light

Professional 1000W LED Moving Head Light – Ultimate Versatility & Performance

Elevate your stage productions, concerts, and events with our high-power 1000W LED Moving Head Light, combining brilliant output, advanced optics, and unmatched flexibility. Featuring an 800W LED module (20,000-hour lifespan), this fixture delivers vibrant, consistent lighting with 7,400K color temperature and Ra>90 high rendering mode for true-to-life colors.

Key Features:
✔ 5°–50° High-Speed Zoom
 – Uniform spot quality at any angle.
✔ Linear Dimming (0–100%) + CMY Mixing – Smooth transitions and rich hues.
✔ 4-Blade Framing + 7 Rotating Gobos – Precision beam shaping and dynamic patterns.
✔ 3200K–7200K CTO Correction – Perfect whites for any scene.
✔ 3-Facet Prism + Flame/Water Effects – Stunning atmospheric visuals.
✔ 540°/270° Pan/Tilt (16bit) – Ultra-precise movement.
✔ Smart Cooling & 39 DMX Channels – Reliable, user-controlled performance.

Ideal for:

  • Concerts & Festivals – Command attention with intense beams and strobes (0–25Hz).

  • Theater & TV Studios – Natural light with high CRI and smooth frost (0–100%).

  • Architectural Lighting – Dynamic gobos and prism effects for immersive displays.

With RDM support, touchscreen control, and silent operation, this moving head is built for professionals who demand power, precision, and creativity. Net weight: 27.5kg | 39CH control.

Light up your vision—where every detail shines.

InquiryDownloadVideo
Share to
Detailed

Technical Specifications

Electrical & Power Specifications

  • Input Voltage: AC 90–240V, 50/60Hz

  • Rated Power: 1,000W

  • Light Source: 800W high-output LED module

  • Light Source Lifespan: 20,000 hours

Optical Performance

  • Color Temperature: 7,400K (adjustable via CTO: 3,200K–7,200K)

  • Color Rendering Index (CRI):

    • Standard Mode: Ra > 70

    • High-Rendering Mode: Ra > 90

  • Optical System: High-precision combined lens assembly

  • Beam Angle (Zoom): 5°–50° (high-speed linear zoom, uniform spot consistency at any angle)

  • Focusing: Linear adjustment with high-precision glass lenses

Beam Shaping & Effects

  • Framing System: 4 independent motorized shutters (individually rotatable up to 90°)

  • Frost Effect: 0–100% linear frost diffusion (independent control)

  • Strobe: Adjustable 0–25Hz (pulse, synchronous/asynchronous strobe effects)

  • Color System:

    • 6 dichroic colors + open

    • Bidirectional rainbow, half-color, and gradient effects

  • CMY Color Mixing: Full linear CMY mixing system

Gobos & Prism Effects

  • Fixed Gobos: 4 replaceable gobos + open (with shake function)

  • Rotating Gobos: 7 glass gobos + open (bi-directional rotation, individual control)

  • Prism: 3-facet rotating prism (forward/reverse rotation)

  • Dynamic Effects: Simulated flame, water flow, and other dynamic movements

Control & Connectivity

  • Control Protocols: DMX512, RDM, Master/Slave, Auto, Sound-Activated

  • DMX Channels: 39CH

  • Software Upgrade: Online firmware updates via DMX

  • Connectors:

    • 3-pin/5-pin XLR (in/out)

    • PowerCON power input

Mechanical & Movement

  • Pan/Tilt: 540° (pan) / 270° (tilt), 16-bit precision

  • Display: 2.8" LCD touchscreen + physical keys (180° reversible, bilingual UI)

  • Cooling System: Intelligent variable-speed fan with temperature monitoring

Physical Specifications

  • Housing: Flame-retardant, high-temperature-resistant composite

  • Mounting: Integrated foldable yoke

  • Net Weight: 27.5 kg

  • Dimensions (L×W×H): 385 × 270 × 690 mm

Packaging Options

  1. Standard Carton:

    • Gross Weight: 33 kg

    • Dimensions: 820 × 400 × 550 mm

  2. 2-in-1 Flight Case:

    • Gross Weight: 98 kg

    • Dimensions: 950 × 580 × 830 mm

Additional Features

  • Energy-Saving Mode: Auto sleep when idle

  • Compliance: Designed for professional stage/studio use
