Professional Spotlight | 560W Beam Moving Head
Equipped with the original 461W OSRAM lamp, this 560W moving head delivers exceptional brightness and a remarkable 4,500-hour lamp life. Its ultra-narrow 1.8° beam, shaped by a large 165mm lens, creates powerful, long-throw projections perfect for defining the space in large venues.
It offers extensive creative control with a rich suite of effects: 17 fixed gobos (with shake/flow effects), a 14-color wheel with half-color and rainbow capabilities, and two advanced, stackable prism wheels—including a unique combination (8+16+24) facet prism—all featuring independent rotation. Motorized 540°/270° pan/tilt with 16-bit accuracy ensures smooth, precise movement.
Ideal for: Creating dramatic aerial beam effects in concert touring, cutting through ambient light at festivals, and adding architectural depth to stage designs in theaters and large-scale production events.
With motorized focus, linear dimming, a variable strobe (0-20Hz), and a dedicated frost filter, it provides complete beam texture control. Operating via 17 DMX channels, it supports DMX512, RDM, master/slave, and sound activation, all manageable through a rotatable 180° LCD interface. Its robust design (19kg) handles a wide voltage input (90V-240V), ensuring global performance reliability.
Model Name: PRC-550Beam
Beam Moving Head light
● Light source: Original 461W OSRAM lamp (included)
● Light source life: 4,500 hours
● Rated power: 560W
● Beam angle: 1.8°
● Optical lens: 165mm
● Fixed Gobo wheel: 17pcs fixed gobos + open, gobo shaking and flow effect
● Color wheel: 14 colors + open, half-color and bidirectional rainbow effect, linear adjustment
● Rainbow wheel: 6-color rainbow wheel
● Prismatic wheel 1: (6+12) faceted prism and 6-faceted linear prism, Frost function, build-up capability, each prism can independently rotate back and forth
● Prism Wheel 2: (8+16+24 ) a combination prism with faces, stackable, each prism can be independently rotated back and forth
● Pan/tilt: 540° / 270°, 16-bit scan accuracy, electronic error correction
● Focusing: Motorized focusing
● Brightness adjustment: linear adjustment from 0 to 100%
● Strobe light: 0-20Hz, synchronized, pulse, speed adjustable
● Frost (frost): 1 piece independent frost effect, soft and natural light spot
● DMX control channels: 17 channels
● Display: LCD screen + touch control keys, can rotate the display 180° in the opposite direction
● Software: Update the software via the DMX connection
● Control signal: DMX512, RDM, Automatic Start, Master/Slave, Sound activation, Built-in programs
● Input voltage: 90V~240V AC, 50/60Hz
● Net Weight: 19.0kgs
● Gross Weight: Flight case(2in1): 63.0kgs
● Product Size: 350×265×550cm
● Packing Size: Flight case(2in1): 690×450×730cm
